1.44 inch 128×128 SPI 240 nits square wearable TFT LCD display

Item	Kingtech 1.44inch 128×128 lcd display
Model No	PV144000YP10B
Resolution	128×128
Outline Dimension	32.6(W)×38.00(H)×2.6(T)
Active Area(mm)	25.50(W)×26.50(H)
Interface	3-wire SPI / 4-wire SPI
Viewing Angle	6 o’ clock
Driving IC	ST7735S
Display Mode	Normally White,Transmissive
Operating Temperature	-20 to +70℃
Storage Temperature	-30 to +80℃
Brightness	240nits
Touch screen	Resistive and capacitive touch screen

For product pricing,customization,or other inquiries:

1.44 inch 128×128 SPI square wearable TFT LCD display .

1. PV144000YP10B mainly application for smart watch and wearable devices
2. It with TN/ 6 o’ clock viewing angel , 128×128 resolution , 3-wire SPI / 4-wire SPI interface , ST7735S Driver IC, 240 nits brightness .
3. And it can custom the capacitive resistive touch panel as customer ‘s requirement .
4. It is super thin. The small size popular for smart watch market.

1.44 inch SPI interface LCD display front view
