China 40 pin 10.1inch mipi dsi lcd display 1000 nits

Item	10.1 inch 1280×800 TFT LCD display
Model No	PV101016LZR40P
Resolution	1280×800
Outline Dimension	229.81595.9
Active Area(mm)	216.96*135.60
Brightness	1000nits
Viewing Angle	All
Interface	MIP
PIN	40
Operating Temperature	-30 to +80℃
Storage Temperature	-30 to +85℃
Board	Can custom HDMI board
Touch Screen	Can custom capacitive touch or resistive touch

For product pricing,customization,or other inquiries:

10.1 inch 1280×800 sunlght readable MIPI LCD display

1. PV101016LZR40P mainly application for industrial device .
2. It with 1280×800 high resolution , MIPI 4LANS interface , IPS full viewing angle , 1000nits high brightness , -30℃~80℃wide work temperature.
3. And it can custom the capacitive resistive touch panel as customer ‘s requirement .
4. It is sunlight readable , it can be well used for both indoor and outdoor .

10.1 inch sunlight readable LCD display front view

10.1 inch sunlight readable LCD display back view
