30 pin 1024×768 10.4 inch screen

Item	10.4 inch 1024×768 IPS LCD display
Model No	PV104004YH30E
Resolution	1024×768
Outline Dimension	225.5176.38.7
Active Area(mm)	210.4*157.8
Interface	LVDS
Viewing Angle	All
Display Mode	Transmissive / Normally Black
Operating Temperature	-30℃ to +80℃
Storage Temperature	-30℃ to +80℃
Brightness	500nits
Touch screen	I2C / USB capacitive touch screen
Board	HDMI board

For product pricing,customization,or other inquiries:

10.4 inch 1024×768 wide temperature LVDS IPS lcd display

PV104004YH30E mainly application for Industrial medical equipment.
It with 1024×768 resolution , LVDS interface , IPS full viewing angle , 500nits high brightness , -30℃~85℃wide work temperature, it with existing capacitive touch panel and HDMI board to support Raspberry PI .
And it can custom the capacitive resistive touch panel as customer ‘s requirement .
It is wide work temperature, it can be well used for both indoor and outdoor.
