3.4 inch 480*480 TFT display with touch panel
| Item | 3.4 inch IPS 480*480 square TFT LCD display |
| Model No. | PV03404G0130E |
| Resolution | 480*480 |
| Outline Dimension (mm) | 70.45*70.32*1.89 |
| Active Area (mm) | 60.48*60.48 |
| Viewing Angle | All |
| Brightness | 300nits |
| Interface | MIPI |
| Backlight | 4*2LED |
| Driving IC | ST7701S |
| PIN No. | 30 |
| Operating Temperature | -20~70 |
| Storage Temperature | -30~80 |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | Medical, hand-held device, industrial,smart home |
For product pricing,customization,or other inquiries:
Share to:
- 3.4 inchTFTdisplay
- 480*480
- Stable supply
- All/Full/Wide/IPS viewing angle
- MIPIinterface
- 300nits brightness/Sunlight readable/High brightness
- Can custom resistive touch and capacitive touch
- Medical, hand-held device, industrial, smart-home
