Home > Products > 5.0 inch 720×1280 MIPI interface IPS view ILI9881D IC TFT lcd display

5.0 inch 720×1280 MIPI interface IPS view ILI9881D IC TFT lcd display

Item	5.0 inch 720×1280 lcd module
Model No	PV05013H0139Q
Resolution	720×1280
Outline Dimension	64.70(H ) x118.70(V) x1.68(T)
Active Area(mm)	62.10(H) x110.40(V)
Interface	MIPI Interface
Viewing Angle	All
Driver	ILI9881D
Display Mode	Transmissive / Normally Black
Operating Temperature	-20℃ to +70℃
Storage Temperature	-30℃ to +80℃
Brightness	350nits
Touch panel	Supprot capacitive touch

For product pricing,customization,or other inquiries:

720×1280 resolution 5 inch MIPI interface IPS portrait screen tft lcd display
1 PV05013H0139Q mainly application for outdoor device ,Industrial ，medical equipment .
2.It with 720X1280 resolution , 350nits brightness , MIPI interface , ILI9881D driver IC, IPS / All / Full / Wide viewing angle.
3.It also can custom touch panel as customer ‘s requirement .
4.It is A grade product and with wide work temperature feature , the good quality well use for Electric motorcycles and e-bikes.

5” TFT LCD dipslay with MIPI interface front view
