500 nits ST7272 3.5 ” 320×240 ips lcd panel

Item	3.5 inch 320×240 IPS TFT LCD
Model No	PV03503LZR54D-V01
Resolution	320×240
Outline Dimension	76.70(W)×63.70(H)×3.26(T)
Active Area(mm)	70.08(W)×52.56(H)
Interface	24-bit RGB interface
Viewing Angle	Full viewing angle / IPS
Driving IC	ST7272
Display Mode	TFT/TRANSMISSIVE
Operating Temperature	-20 to +70℃
Storage Temperature	-30 to +80℃
Brightness	500nits
Touch screen	Resistive and capacitive touch screen

For product pricing,customization,or other inquiries:

3.5 inch 320×240 resolution RGB interface LCD
1.PV03503LZR54D-V01 mainly application for handheld device
2.It with 320×240 resolution , 24-bit RGB interface, ST7272 Driver IC, 250nits brightness.
3.And it can custom capacitive and resistive touch panel as customer ‘s requirement;
4.It is A grade product , the good quality well use for Industrial ，medical application.

3.5 inch 3.5 inch 480×272 resolution RGB interface display Front view.

PV03503LZR54D-V01
