7.0 inch 1280×800 MIPI all view landscap screen with JD9366 IC TFT LCD display
| Item | 7inch 1280X800 IPS MIPI interface display |
| Model No | PV07015YP24R |
| Resolution | 1280 x 800 |
| Outline Dimension | 170*115*4.75 |
| Active Area(mm) | 150.72*94.2 |
| Interface | MIPI Interface |
| Viewing Angle | All |
| Driver IC | JD9366 |
| Display Mode | Transmissive / Normally Black |
| Operating Temperature | -20℃ to +70℃ |
| Storage Temperature | -30℃ to +80℃ |
| Brightness | 300nits |
| Touch screen | capacitive touch screen |
For product pricing,customization,or other inquiries:
Share to:
All view 7 inch 1280×800 resolution IPS MIPI interface TFT LCD display
1. PV07015YP24R mainly application for Industrial ，medical equipment .
2. It with1280x800 resolution , 300nits brightness, MIPI interface, JD9366 Driver IC, IPS / Full / All/ Wide viewing angle, existing capacitive touch panel .
3. It also can custom touch panel as customer ‘s requirement .
4. It is A grade product , the good quality well use for Industrial ，medical application.
IPS 7.0 inch TFT LCD front view
MIPI interface 7.0 inch TFT LCD back view
