7-inch 800×480 dots LCD module
| Item | 7.0 inch TN 800×480 LCD module |
| Model No. | PV07048Y0150Z |
| Resolution | 800*480 |
| Outline Dimension (mm) | 164.9*100*5.7 |
| Active Area (mm) | 154.08*85.92 |
| Viewing Angle | 12 O’clock |
| Brightness | 500nits |
| Interface | 24bit RGB |
| Backlight | 3*9LED |
| Pin nums | 50 |
| Driving IC | / |
| PIN No. | 50 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Resistive touch and capacitive touch optional |
| Application | Industrial, Medical, Digital photo frame, portable DVD, video doorbell, video phone. |
For product pricing,customization,or other inquiries:
Share to:
- standard 50pins,support RGB interface
- Brightness 500nits, High brightness, Sunlight readable, Outdoor
- Competitive price
- Resistive touch and capacitive touch can be customized.
