Kingtech 3.4 inch 800*800 round TFT display supply very stable
| Item | 3.4inch IPS 800*800 round LCD display |
| Model No. | PV03405D0130F |
| Resolution | 800*800 |
| Outline Dimension (mm) | 96.6*99.79* 3.8 |
| Active Area (mm) | φ 87.6 |
| Viewing Angle | All |
| Brightness | 1000nits/Sunlight readable/High brightness/Outdoor |
| Interface | MIPI |
| Backlight | 5*2LED |
| Driving IC | ILI9881C |
| PIN No. | 30 |
| Operating Temperature | -30~80 |
| Storage Temperature | -30~80 |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | Medical, hand-held device, industrial, smart home |
For product pricing,customization,or other inquiries:
Share to:
- 3.4 inchTFTdisplay
- 800*800
- Stable supply
- All/Full/Wide/IPS viewing angle
- Wide temperature/-30~80C
- MIPIinterface
- 1000nits brightness/Sunlight readable/High brightness/outdoor
- Can custom resistive touch and capacitive touch
- Medical, hand-held device, industrial, smart-home
