Kingtech 4.0 inch 720*720 Round TFT display supply very stable.
For product pricing,customization,or other inquiries:
Share to:
- 4.0 inchTFT display
- 720*720
- Stable supply
- All/Full/Wide/IPS viewing angle
- MIPIinterface
- 300nits brightness/Sunlight readable/High brightness
- Can custom resistive touch and capacitive touch
- Medical, hand-held device, industrial, smart home
| Item | 4.0 inch IPS 720*720 square TFT display for smart home |
| Model No. | PV04016D0130Q |
| Resolution | 720*720 |
| Outline Dimension (mm) | 105.61*109.87*2.09 |
| Active Area (mm) | φ 101.52 |
| Viewing Angle | All |
| Brightness | 300nits |
| Interface | MIPI |
| Backlight | 6*2LED |
| Driving IC | SC7707 |
| PIN No. | 30 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | E-Bike, Medical, hand-held device, industrial, smart home |
Kingtech 4.0 inch 720*720 TFT display supply very stable. This 4.0 inch supports MIPI interface. In addition, the 4.0 inch 720*720 square TFT display module brightness is 300 nits, and this 4.0 inch display is All viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
The 4.0 inch 720*720 square TFT display module can be used for E-Bike, Medical, hand-held device, industrial, smart home or others.
